PeopleLink Active LED Indoor SeriesLED Video Wall

LED Video Wall line, available in 3 models (P1.5, P1.8, P2.5). View the verified model specifications and download the full datasheet.

Product datasheet
Download the full datasheets
Complete specifications for each PeopleLink Active LED Indoor Series model in PDF.
Overview

What is the PeopleLink Active LED Indoor Series?

The PeopleLink Active LED Indoor Series is a direct-view LED video wall series, available in 3 models (P1.5, P1.8, P2.5), built for indoor lobbies, control rooms and meeting spaces. Built for bright, seamless large-format visuals. Because PeopleLink builds its Active LED range as one OEM, it integrates cleanly with PeopleLink processing, control and room solutions. The model specifications below are drawn from the official datasheets, and the full PDF for each model is available on request.

Using high-quality LED, high brightness utilization

High contrast

Lightweight and easy to disassemble

PeopleLink Active LED Indoor Series
Specifications

PeopleLink Active LED Indoor Series model specifications

Verified from the official datasheets. Download the full PDF for any model below.

SpecificationP1.5P1.8P2.5
Pitch(mm)1.531.82.5
LED ModelSMD1212SMD1212SMD2020
LED TypeCopper wireCopper wireCopper wire
Resolution128*64128*64128*64
Size ± Tolerance (mm × mm × mm)319.9±0.1*159.9±0.1*15±0.2319.9±0.1*159.9±0.1*15±0.2319.9±0.1*159.9±0.1*14.2±0.2
Weight ± Tolerance (kg)0.531±0.050.531±0.050.42±0.05
Flatness (mm)＜0.2＜0.2＜0.2
Pixel density(dot/㎡)423729288000160000
Brightness(cd/m2)≥600≥600 nits≥600 nits
Color temperature(k)3000～15000 (Adjustable)3000～15000 (Adjustable)3000～15000 (Adjustable)
Horizontal Angle of view(°)≥150≥150≥150
Vertical Angle of view(°)≥130≥130≥130
Viewing distance≥1.5 Meter≥1.5 Meter≥2.5 Meter
Max power consumption of a module≤20W≤20W≤20W
Average power consumption≤130W/㎡≤130W/㎡≤130W/㎡
Maximum active power consumption≤390W/㎡≤390W/㎡≤390W/㎡
Working voltage(V)555
Signal input interface typeHUB75HUB75HUB75
Scanning method525232
frame frequency(Hz)50/6050/6050/60
refresh rate(Hz)384038403840
Drive modeConstant current driverConstant current driverConstant current driver
Gray(bit)131313
Continuous working hours≥7*24hrs, (support continuous uninterrupted display)≥7*24hrs, (support continuous uninterrupted display)≥7*24hrs, (support continuous uninterrupted display)
Average time without failureUpto 5000 HoursUpto 5000 HoursUpto 5000 Hours
LED Lifetime, Typical(hrs)100000100000100000
Operating temperature(℃)-20-+40-20-+40-20-+40
Storage temperature(℃)-20-+60-20-+60-20-+60
Operating humidity(RH)10％-60％ (No condensation)10％-60％ (No condensation)10％-60％ (No condensation)
Storage humidity(RH)10％-65％(No condensation)10％-65％(No condensation)10％-65％(No condensation)
Ingress ProtectionIP30IP30IP30
