PeopleLink
Datasheet

PeopleLink Elite 4K 12x CameraProfessional PTZ Camera

4K UHD PTZ camera with 12X optical zoom for boardrooms and large meeting rooms. View the verified specifications and download the full datasheet.

Camera datasheet
Download the full datasheet
Complete specifications for the PeopleLink Elite 4K 12x Camera in PDF.
Overview

What is the PeopleLink Elite 4K 12x Camera?

The PeopleLink Elite 4K 12x Camera is a professional PTZ camera built for boardrooms and large meeting rooms. It captures 4K UHD video and offers 12X optical zoom, so a single camera can frame the whole room and reach detail at distance. It includes AI presenter tracking that keeps the active speaker framed as they move. It connects over standard interfaces and works with common video conferencing platforms, and because PeopleLink is one OEM it pairs cleanly with PeopleLink audio, control and room solutions. The summary specifications below are drawn from the official datasheet, and the full PDF is available on request.

4K60FPS

Utilizes a UHD CMOS sensor with a 1/2.5-inch size and 8.51 million pixels. Both models deliver images at a resolution of 4K at 60fps and are backward compatible with resolutions such as 1080P/720P.

Long Optical Zoom + UHD Lens

Equipped with 4K Ultra HD wide-angle lens, supporting a maximum 12x optical zoom, and an 80.8° horizontal FoV.

AI Presenter Tracking

Equipped with in-house-developed ReID technology, the device identifies the speaker's figure, appearance, and outfit. As the speaker moves within the room, the camera automatically tracks them, ensuring the target remains centered. Even if there are interferences or the speaker exits the frame, the camera swiftly recaptures and tracks them upon reentry.

PeopleLink Elite 4K 12x Camera
Specifications

PeopleLink Elite 4K 12x Camera specifications

Verified from the official datasheet. Download the full PDF for complete details.

Camera Spec
Sensor1/2.5 inches, CMOS, Effective Pixels: 8.51 Megapixels
Lens12X Optical Zoom
Focal Lengthf=3.47mm~41.65mm, F1.84~F3.72
Horizontal FOV80.8° ~ 7.5°
Vertical FOV49.9° ~ 4.3°
Signal SystemHDMI: 4KP60, 4KP59.94, 4KP50, 4KP30, 4KP29.97, 4KP25, 1080P60, 1080P59.94, 1080P50, 1080P30, 1080P29.97, 1080I60, 1080I59.94, 1080I50, 1080P25, 720P60, 720P59.94
Scanning ModeProgressive
Digital Zoom16×
Minimum Illumination0.5Lux @ (F1.8, AGC ON)
Shutter1/30s ~ 1/10000s
White BalanceAuto, Indoor, Outdoor, One Push, Manual
Backlight CompensationSupport
Digital Noise Reduction3D Digital Noise Reduction
SNR≥ 55dB
Tilt Angle-30° ~ +90°
Pan Angle±162.5°
Pan Speed1.8° ~ 80° /s
Tilt Speed1.5° ~ 49° /s
Image FlipSupport
Image FreezeSupport
PoE+Support
Preset Position255
Preset Accuracy0.1°
USB Video FormatYUY2: Max.1080P30(USB3.0) YUY2: Max.1080P5(USB2.0) H.264 AVC: Max.2160P30; H.265 HEVC: Max.2160P30 MJPEG: Max.2160P30
HD Output1 × HDMI: Version 2.0 1 × 3G-SDI: BNC, 800mVp-p, 75Ω, as per SMPTE424M standard
USB Interface1 × USB2.0: Type-C(Optional upgrade to USB3.0)
Control Interface1 × RS485: 3pin phoenix port, Max Distance: 1200m, Protocol: VISCA / Pelco-D / Pelco-P
Network Spec
Audio Bit Rate96Kbps, 128Kbps
ProtocolsDante AV-H, NDI®|HX3, SRT, TCP/IP, HTTP, RTSP, RTMP(s), Onvif, DHCP, GB/T 28181, Multicast, Free-D etc.
Audio CompressionAAC, G711A
Video CompressionH.265 / H.264 / MJPEG
Video StreamFirst Stream, Second Stream
First Stream Resolution3840x2160, 1920x1080, 1280x720, 1024x576 etc.
Second Stream Resolution720×480, 320×240 etc.
Video Bit RateFirst Stream: 32kbps~51200kbps Second Stream: 32kbps~20480kbps
Bit Rate ControlVBR, CBR
Frame Rate50Hz: 1fps~50fps, 60Hz: 1fps~60fps
USB Spec
Operating System SupportedWindows 7 (only supports UVC1.1 features), Windows 8 and above version, Mac OS X, Linux 2.4.6 and above version, Android needs to include the version of UVC-related drivers
USB AudioSupport
USB Video Communication ProtocolUVC 1.1~1.5
Color System / CompressionYUY2 / H.264 / MJPEG / H.265
UVC PTZ ControlSupport
I/O
Network Interface1 × RJ45: 10M/100M/1000M adaptive Ethernet
Audio Interface1 × LINE IN: 3.5mm Jack
RESTORE ButtonSupport
Power InterfaceJEITA type (DC IN 12V)
Control Interface1 × RS232 IN: 8pin Mini DIN, Max Distance: 30m, Protocol: VISCA / Pelco-D / Pelco-P; 1 × RS232 OUT: 8pin Mini DIN, Max Distance: 30m, Protocol: VISCA only
Generic Spec
DisplaySupport
Input VoltageDC 12V /PoE+ (802.3at)
Input Current2A (Max.)
Operating Temperature0° C ~ 40° C
Storage Temperature-40° C ~ 60° C
Power Consumption18W (Max.)
Dimension223mm (W) × 163mm (D) × 166mm (H)
Net Weight1.8kg

Need help choosing the right product for your room or budget? We will recommend the right model.

Talk to Sales
FAQs

Questions, answered.

The PeopleLink Elite 4K 12x Camera captures 4K UHD video and offers 12X optical zoom.

The PeopleLink Elite 4K 12x Camera uses a 1/2.5 inches, CMOS, Effective Pixels: 8.51 Megapixels, with a 80.8° ~ 7.5° field of view.

Yes. The PeopleLink Elite 4K 12x Camera provides AI tracking and auto framing that keep the active presenter framed as they move.

The PeopleLink Elite 4K 12x Camera connects over standard interfaces including 1 × HDMI: Version 2.0 1 × 3G-SDI: BNC, 800mVp-p, 75Ω, as per SMPTE424M standard, with PoE support, and works with common video conferencing platforms. As one OEM, PeopleLink also supplies matching audio, control and room solutions.

Use the download button on this page to request the full PeopleLink Elite 4K 12x Camera PDF datasheet. Share a few contact details and the complete datasheet opens immediately, and a PeopleLink specialist can follow up with pricing and configuration.
