PeopleLink Elite XL Series 30X CameraProfessional PTZ Camera

Full HD 1080p PTZ camera with 30X optical zoom and 8X digital zoom for large halls and auditoriums. View the verified specifications and download the full datasheet.

Camera datasheet
Download the full datasheet
Complete specifications for the PeopleLink Elite XL Series 30X Camera in PDF.
Overview

What is the PeopleLink Elite XL Series 30X Camera?

The PeopleLink Elite XL Series 30X Camera is a professional PTZ camera built for large halls and auditoriums. It captures Full HD 1080p video and offers 30X optical zoom and 8X digital zoom, so a single camera can frame the whole room and reach detail at distance. It includes AI presenter tracking that keeps the active speaker framed as they move. It connects over standard interfaces and works with common video conferencing platforms, and because PeopleLink is one OEM it pairs cleanly with PeopleLink audio, control and room solutions. The summary specifications below are drawn from the official datasheet, and the full PDF is available on request.

1080P Full HD

Utilizing a 1/2.8-inch, 2.07 million effective pixel HD CMOS sensor, these cameras achieve a maximum resolution of 1920×1080.

High-Quality Optical Zoom + HD Lens

Utilizes a high-quality ultra-high-resolution full HD telephoto lens with a maximum 30x optical zoom and a 60.7° horizontal FoV.

ISP Image Processing Algorithm

It uses ISP image processing algorithms to enhance white balance and automatic exposure functions, significantly improving the camera's image output. Widely applied in industries such as education recording, remote education, video conferencing, live streaming, and broadcasting.

PeopleLink Elite XL Series 30X Camera
Specifications

PeopleLink Elite XL Series 30X Camera specifications

Verified from the official datasheet. Download the full PDF for complete details.

Camera Spec
Sensor1/2.8 inches, CMOS, Effective Pixels: 2.07 Megapixels
Lens30x Optical Zoom
Focal Lengthf4.42mm ~ 132.6mm, F1.8 ~ F2.8
Horizontal FOV60.7° ~ 2.28°
Vertical FOV34.1° ~ 1.28°
Scanning ModeProgressive
Digital Zoom8X
Minimum Illumination0.5Lux @ (F1.8, AGC ON)
Shutter1/30s ~ 1/10000s
White BalanceAuto, Indoor, Outdoor, One Push, Manual, VAR
Backlight CompensationSupport
Digital Noise Reduction2D&3D Digital Noise Reduction
SNR≥ 55dB
Pan Angle±170°
Tilt Angle-30° ~ +90°
Pan Speed1.7° ~ 100° /s
Tilt Speed1.7° ~ 69.9° /s
Image FlipSupport
Image FreezeSupport
Preset Position255
Preset Accuracy0.1°
Signal SystemHDMI, 3G-SDI: 1080P60, 1080P59.94, 1080P50, 1080I60, 1080I59.94, 1080I50, 1080P30, 1080P29.97, 1080P25, 720P60, 720P59.94, 720P50
HD Output1 x HDMI: Version 1.3; 1 x 3G-SDI: BNC , 800mVp-p, 75Ω, as per SMPTE 424M standard
ProtocolsFULL NDI, NDI|HX2, TCP/IP, HTTP, RTSP, RTMP, RTMP(s), Onvif, DHCP, Multicast, ,SRT,GB/T28181 etc.
Microphone ArrayBuilt-in dual microphones, 100Hz to 16KHz frequency response.
Analog Audio Input/OutputSupport 3.5mm Line- In; Support 3.5mm Line-Out
Digital Audio OutputSupport HDMI, USB, LAN, 3G-SDI etc
I/O
Audio Interface1 x Line In, 3.5mm Jack 1 x Line Out, 3.5mm Jack
Control Interface1 x RS485: 2pin phoenix port, Max Distance: 1200m, Protocol: VISCA / Pelco-D / Pelco-P; 1 x RS232 IN: 8pin Mini DIN, Max Distance:30m, Protocol: VISCA / Pelco-D / Pelco-P; 1 x RS232 OUT: 8pin Mini DIN, Max Distance: 30m, Protocol: VISCA only
Power InterfaceJEITA type (DC IN 12V)
Network Spec
Video CompressionH.264 / MJPEG
Video StreamFirst Stream, Second Stream
First Stream Resolution1920x1080, 1280x720, 1024x576 etc.
Second Stream Resolution1280x720,1024x576,720x576 etc.
Video Bit Rate32kbps~20480kbps
Bit Rate ControlVBR, CBR
Frame Rate1fps ~ 60fps
Audio CompressionAAC
Audio Bit Rate96Kbps, 128Kbps, 256Kbps
USB Spec
Operating System SupportedWindows 7 (only supports UVC1.1 features), Windows 8 and above version, Mac OS X, Linux 2.4.6 and above version, Android needs to include the version of UVC-related drivers
Color System / System / CompressionYUY2 / H.264 / MJPEG
Video FormatSupport a variety of different frame rates and resolution video formats, up to 1080p60 YUY2 output
USB Audio32K Sampling Rate, Support UAC2.0
USB Video Communication ProtocolUVC 1.1~1.5
UVC PTZ ControlSupport
Generic Spec
Input VoltageDC 12V / PoE+ (802.3at)
Input Current1.5 A (Max.)
Operating Temperature0° C ~ 40° C
Storage Temperature-40° C ~ 60° C
Power Consumption15W (Max.)
Dimension142mm (W)×169mm (D)×175mm (H)
Net Weight1.5kg

Need help choosing the right product for your room or budget? We will recommend the right model.

Talk to Sales
FAQs

Questions, answered.

The PeopleLink Elite XL Series 30X Camera captures Full HD 1080p video and offers 30X optical zoom and 8X digital zoom.

The PeopleLink Elite XL Series 30X Camera uses a 1/2.8 inches, CMOS, Effective Pixels: 2.07 Megapixels, with a 60.7° ~ 2.28° field of view.

Yes. The PeopleLink Elite XL Series 30X Camera provides AI tracking and auto framing that keep the active presenter framed as they move.

The PeopleLink Elite XL Series 30X Camera connects over standard interfaces including 1 x HDMI: Version 1.3; 1 x 3G-SDI: BNC , 800mVp-p, 75Ω, as per SMPTE 424M standard, and works with common video conferencing platforms. As one OEM, PeopleLink also supplies matching audio, control and room solutions.

Use the download button on this page to request the full PeopleLink Elite XL Series 30X Camera PDF datasheet. Share a few contact details and the complete datasheet opens immediately, and a PeopleLink specialist can follow up with pricing and configuration.
