What is the Pixel Pitch of the PeopleLink Active LED 1.8?

It has a 1.8mm Pixel Pitch with a Pixel Density of 288,000 dots per square metre. That suits Conference Halls, Meeting Rooms and Multipurpose Halls where the nearest seats are a few metres back from the wall. Viewing angles of at least 150 degrees horizontal and 130 degrees vertical keep side seats on the same picture.

Can the Colour Temperature be adjusted for different rooms?

Yes. Colour Temperature is adjustable from 3000K to 15000K, so the wall can be tuned to warm chamber lighting or a cooler training room. The display refreshes at 3840 Hz for smooth motion during video playback. Both settings are handled at commissioning and can be revisited later.

How is it built for long term use in a busy hall?

It uses Single Lamp Maintenance and a lightweight modular design, so a fault is fixed at lamp level rather than by swapping a whole cabinet. Average power consumption of 130 W per square metre or less keeps running load predictable on a large wall. It is built for demanding indoor environments such as halls in daily use.

Does it work with PeopleLink room systems?

Yes. PeopleLink builds Displays, Cameras, Audio and Room Solutions as one AV OEM, so the wall becomes part of a room design rather than a separate purchase. That keeps commissioning and later support with one vendor across a multi site rollout.

How far should viewers sit from the Active LED 1.8?

A 1.8mm Pixel Pitch is designed for rooms where viewers are a few metres from the wall, such as Training Rooms, Conference Halls and Multipurpose Halls. Share your room plan with a PeopleLink specialist for a sizing recommendation.

Who installs and supports the display?

Installation, service and support are delivered through PeopleLink Partners and Resellers in your region, with PeopleLink AV Specialists supporting them on sizing and integration.

Active LED · Indoor LED Video Wall

PeopleLink Active LED 1.8P1.8 Direct View Indoor LED Video Wall for Conference Halls and Indoor Events

The PeopleLink Active LED 1.8 is a Direct View LED Video Wall for Conference Halls, Meeting Rooms and Indoor Events.

1.8mm Pixel pitch
288,000 dots/m2 Pixel density
>=600 nits Brightness

Request a Quote WhatsApp

1 / 4

One OEM
Hardware and Software from a single vendor
Deployed Globally
Enterprise, Government, Education and Healthcare
Regional Partner Support
Service and Support through PeopleLink Partners and Resellers in your region
Published Specifications
PDF Datasheets available for PeopleLink products

Overview

What a P1.8 Indoor LED Video Wall does in a Conference Hall

The PeopleLink Active LED 1.8 is a Direct View LED Video Wall for Conference Halls, Meeting Rooms and Indoor Events. It pairs a 1.8mm Pixel Pitch and 288,000 dots per square metre with SMD1212 Copper Wire lamps for high contrast at 600 nits or more. Colour Temperature is adjustable from 3000K to 15000K and the panel refreshes at 3840 Hz, which keeps long sessions comfortable and motion smooth. Training Rooms, Council Chambers and Assembly Halls run it beside PeopleLink Cameras and Audio in the same room design. Lightweight cabinets and Single Lamp Maintenance suit organisations standardising one wall specification across several sites.

The PeopleLink Active LED 1.8 is a high-performance commercial-grade display designed to elevate visual experiences in conference halls, meeting rooms, and indoor events. Utilizing SMD1212 technology with copper wire, it delivers high contrast and brightness for sharp, direct-view visuals. This display is engineered for versatility, capable of forming expansive video walls for cinemas or sports venues.

Its lightweight design allows for easy disassembly, while its single-lamp maintenance capability ensures low-cost, long-term operation. It is a reliable choice for demanding environments.

Pixel Pitch: 1.83 mm for fine detail
High Pixel Density: 423,729 dots/m²
Brightness: ≥600 nits
Smooth Motion: Refresh rate of 3840 Hz
Wide Viewing Angle: ≥150° Horizontal and ≥130° Vertical
Efficient Power: Average power consumption ≤130W/m²
Easy Maintenance: Supports single lamp maintenance
Reliability: Single-lamp maintenance and modular design for long-term service

Key Specifications

Headline specifications from the product Datasheet. Full model-by-model detail is in the PDF.

Item	PeopleLink Active LED 1.8
Pixel pitch	1.8mm
Pixel density	288,000 dots/m2
Brightness	>=600 nits
Refresh rate	3840 Hz

Technical Specifications

Display

Pixel Pitch	1.8 mm
Pixel Density	288,000 dots/m2
LED Technology	SMD1212 copper wire
Brightness	>=600 nits
Refresh Rate	3840 Hz
Viewing Angle	>=150 degrees H / >=130 degrees V
Color Temperature	3000K - 15000K (adjustable)
Power Consumption	<=130 W/m2 (average)
Maintenance	Single lamp maintenance

Rooms It Serves

Conference Halls

Sharp Direct View detail at 1.8mm Pixel Pitch for presentations and large format content.

Meeting Rooms

High contrast visuals at 600 nits or more for collaboration and data display.

Indoor Events

Modular LED Video Wall for stages, cinemas and venues, built from lightweight cabinets.

Where a LED Video Wall Fits in Your Organisation

How organisations deploy a LED Video Wall, and what changes for the teams that use it

Enterprise

Training Centre Wall for a Bank

A bank's central training centre installs an Active LED 1.8 wall for classroom-style sessions of up to a full hall. The 1.8mm Pixel Pitch and 288,000 dots per square metre keep slides and video crisp from mid-room seating, and Adjustable Colour Temperature from 3000K to 15000K matches the room lighting for long sessions. Trainers run content and PeopleLink Camera feeds through one seamless display.

Government

Council Chamber Display for a Municipal Corporation

A municipal corporation replaces the projectors in its Council Chamber with an Active LED 1.8 wall for sittings and public webcasts. High contrast and brightness of at least 600 nits keep agendas and budget tables readable under the chamber's own lighting, with no need to dim the room. Single Lamp Maintenance keeps servicing simple for the facilities team between sittings. The wall pairs with PeopleLink Cameras and Audio so proceedings are recorded and streamed from the same room design rather than a separate broadcast rig.

Education

Multipurpose Hall Screen for a School Group

A school group in the Gulf region fits its Multipurpose Hall with an Active LED 1.8 wall for assemblies, Indoor Events and parent briefings. Lightweight modular cabinets mount on the hall's existing structure without heavy steelwork. Adjustable Colour Temperature from 3000K to 15000K lets staff soften the picture for long morning assemblies and brighten it for evening shows. Video from PeopleLink Cameras, presentation slides and cinema style screenings all run through the one seamless wall, so the hall serves several purposes without extra equipment.

Not sure which model fits your Conference Halls or Meeting Rooms?

Tell us the room size and seating. A PeopleLink specialist will recommend the right model.

Talk to Sales

How It Compares

Capability	PeopleLink Active LED 1.8	Typical Alternative
Pixel pitch	1.8mm direct-view	Coarser pitch typical
Image format	Seamless LED wall	Visible bezels on tiled LCD
Color control	Adjustable 3000K - 15000K	Fixed temperature
Maintenance	Single lamp maintenance	Whole-module swap

Why PeopleLink

Hardware and Software

Displays, Cameras, Audio and Collaboration Platforms, built by one OEM.

Integrates Cleanly

PeopleLink Displays pair with PeopleLink Cameras, Audio and Room Solutions out of the box.

Deployed Globally

Trusted across Enterprise, Government, Education and Healthcare environments.

Specialist Support

Talk to PeopleLink AV Specialists for sizing, integration and rollout.

Planning a multi-room or campus rollout?

Get one consolidated quote covering Hardware, Software and Installation from One OEM.

Request a Quote

Frequently Asked Questions

Explore Related Resources

In the Room

LED Video Walls in Lecture Halls and Training Rooms

Video wall installations photographed on site.

Lecture hall with a wall of student displays and a video wall — Lecture Hall Video WallMulti-Display Teaching Space

University lecture theatre with tiered seating, an Active LED wall and a presenter at a PeopleLink digital podium — University Lecture TheatreActive LED Wall with Digital Podium

Presenter at a digital podium addressing an audience in front of a video wall — Corporate Training SessionDigital Podium with Multi-Screen Wall

Talk to a PeopleLink LED Specialist about Indoor LED Walls

Wall size, viewing distance and content in one message. We reply with the right Pixel Pitch and Cabinet layout.
