Video Mixer & Tracking Controller
The PeopleLink Video Mixer & Tracking Controller is an AV control device that combines a seamless video mixer and switcher with camera auto-tracking control. It accepts 2 HDMI and 4 SDI inputs and provides seamless 6x1+1 scaler switching with no jitter and no blank screen, up to 1080P at 60Hz output, plus an adjustable image freeze and web control. Over RS232 and Ethernet it works with a central controller or compatible conference main unit to drive camera auto-tracking. Because PeopleLink is one OEM, it pairs cleanly with PeopleLink cameras, audio and room solutions. The specifications below are drawn from the official datasheet, and the full PDF is available on request.
Product Overview
Key Features
- 2 HDMI + 4 HD/3G SDI input, 1+1 HDMI output.
- 6×1+1 seamless scaler switcher.
- Maximum supported output resolution is 1080P@60Hz.
- Seamless switching with no jitter and no blank screen.
- Adjustable image freezing function.
- Web control functionality.
Technical Specifications
| Inputs | 2x HDMI input, 4x SDI input |
| Outputs | 1+1 HDMI output, 1x USB Out |
| Connectors | 2x HDMI-A, 1x female DP9 and 1x male DP9, 1x RJ45 for Ethernet |
| HDMI Quantity / Connector | HDMI x2, HDMI-A connectors |
| HDMI Pixel Bandwidth | 165MHz |
| HDMI Protocol | HDMI 1.3a standard, HDCP 1.3 protocol, DVI 1.0 protocol |
| HDMI Supported Resolution | 1280x720@50/60Hz; 1920x1080@25/30/50/60Hz |
| HDMI Transmission Distance | Less than 35m |
| SDI Quantity / Connector | SDI x4, BNC female connectors |
| SDI Video Format | SDI, 1.485Gbps HD-SDI and 2.97Gbps 3G-SDI |
| SDI Transmission Distance | 3G-SDI up to 100m with certified SDI professional cable |
| Signal Format / Quantity | HDMI x2 |
| Connector | HDMI-A connectors |
| Pixel Bandwidth | 165MHz |
| Supported Resolution | 1280x720@50/60Hz; 1920x1080@25/30/50/60Hz (incl. 1080i 50/60Hz) |
| Transmission Distance | HDMI up to 7m with certified HDMI professional cable |
| Control | RS232 control, Ethernet control, front panel control |
| Dimensions (mm) | 483L x 260W x 43.6D |
| Weight | 3kg |
| Color | Black |
Where It Fits
Conference rooms
Seamless switching between HDMI and SDI sources with no jitter.
Auditoriums and events
Multi-source mixing with adjustable image freeze and web control.
Tracking setups
RS232 and Ethernet control for camera auto-tracking workflows.
How It Compares
| Capability | Video Mixer & Tracking Controller | Typical Alternative |
|---|---|---|
| Inputs | 2 HDMI and 4 HD/3G-SDI | HDMI inputs only |
| Switching | Seamless 6x1+1, no jitter | Switching with blank frames |
| Control | RS232, Ethernet and web control | Front panel only |
| Tracking | Drives camera auto-tracking | No tracking integration |
Why PeopleLink
Hardware + software
Cameras, audio, control and collaboration platforms, built by one OEM.
Integrates cleanly
PeopleLink accessories pair with PeopleLink cameras, audio and room solutions out of the box.
Deployed globally
Trusted across enterprise, government, education and healthcare environments.
Specialist support
Talk to PeopleLink AV specialists for sizing, integration and rollout.
Frequently Asked Questions
What is the PeopleLink Video Mixer & Tracking Controller?
It is an AV control device that combines a seamless video mixer and switcher with camera auto-tracking control, accepting 2 HDMI and 4 SDI inputs and switching up to 1080P at 60Hz.
How many inputs and outputs does it have?
It provides 2 HDMI inputs and 4 HD/3G-SDI inputs with a 1+1 HDMI output and a USB output, using a 6x1+1 seamless scaler switcher.
Does it support camera auto-tracking?
Yes. Over RS232 and Ethernet it works with a central controller or compatible conference main unit to drive camera auto-tracking.
What is the maximum output resolution?
The maximum supported output resolution is 1080P at 60Hz, with seamless switching that has no jitter and no blank screen.
