What is the Pixel Pitch of the PeopleLink Active LED 1.86 Flexible?

It has a 1.86mm Pixel Pitch built on SMD1515GOB technology, with a Pixel Density of 289,050 dots per square metre. The pitch suits Lobbies, Retail Floors and Public Spaces where people view the wall from a few metres rather than at arm's length. GOB encapsulation protects the lamps in areas with heavy footfall.

How does the flexible, magnetic design work on a Curved Wall?

Modules mount magnetically without tools and bend to a 500mm radius, so the wall follows columns, cylinders and wave shaped surfaces. Each module measures 320mm by 160mm at 10mm thick, which keeps the finished surface close to the architecture. Because modules are upgradable, a shaped installation can be extended or refreshed later.

How bright is the display and what is the Viewing Angle?

Brightness is 600 to 800 nits with a 10000:1 Contrast Ratio and a 160 by 160 degree Viewing Angle. Colour Temperature is adjustable from 5000K to 10000K, so the wall can be matched to store, lobby or stage lighting rather than fighting it. Colour Processing at 14 to 18 bit keeps brand gradients smooth.

How is the LED Video Wall serviced in a Public Space?

It works from minus 20C to 60C and uses Front Service Maintenance, so a technician reaches a module from the front rather than needing rear access. That matters when the wall is wrapped around a column or built into a set. Modules are upgradable, which keeps a long lived installation serviceable.

Does it work with PeopleLink room systems?

Yes. PeopleLink builds Displays, Cameras, Audio and Room Solutions as one AV OEM, so a shaped wall can be driven as part of a wider room or venue setup. Sourcing display, capture and sound from one vendor keeps commissioning and later support straightforward.

What is the difference between the 1.53 Flexible and the 1.86 Flexible?

Both share the magnetic, bendable module, the GOB surface and the 500mm Bending Radius. The 1.86 Flexible has a 1.86mm Pixel Pitch and 289,050 dots per square metre, suited to slightly longer viewing distances. A PeopleLink specialist can advise which pitch fits your space.

Who installs and supports the display?

Installation, service and support are delivered through PeopleLink Partners and Resellers in your region, with PeopleLink AV Specialists supporting them on sizing and integration.

Active LED · Flexible LED Display

PeopleLink Active LED 1.86 FlexibleP1.86 Flexible Curved LED Wall for Lobbies, Retail and Stage Sets

The PeopleLink Active LED 1.86 Flexible is a bendable LED Video Wall for curved, cylindrical and wave shaped indoor installations.

1.86mm Pixel pitch
600-800 nits Brightness
160 degrees Viewing angle

Request a Quote WhatsApp

1 / 5

One OEM
Hardware and Software from a single vendor
Deployed Globally
Enterprise, Government, Education and Healthcare
Regional Partner Support
Service and Support through PeopleLink Partners and Resellers in your region
Published Specifications
PDF Datasheets available for PeopleLink products

Overview

What a Flexible Bendable LED Display does on a Curved Wall

The PeopleLink Active LED 1.86 Flexible is a bendable LED Video Wall for curved, cylindrical and wave shaped indoor installations. Its 1.86mm Pixel Pitch on SMD1515GOB lamps gives a Pixel Density of 289,050 dots per square metre behind a GOB protected surface built for public traffic. Brightness of 600 to 800 nits, a 10000:1 Contrast Ratio and a 160 by 160 degree Viewing Angle carry the image around a curve. Retail Flagships, Corporate Lobbies, Museums, Exhibitions and Theatres use it, and PeopleLink Cameras and Audio pair with it for streamed events. Magnetic mounting lets a fit out team build it inside a space that stays open for business.

The PeopleLink P1.86 Indoor Flexible LED Display is a premium fine-pitch LED solution designed for creative indoor installations. Its 1.86 mm pixel pitch delivers sharp visuals, vibrant colors, and outstanding image clarity. The flexible module design supports curved, cylindrical, wave-shaped, and custom display configurations. Its lightweight and bendable construction enables easy installation on convex and concave surfaces.

High brightness and wide viewing angles ensure a clear and immersive viewing experience. Superior color consistency delivers seamless visuals across the entire display. It is ideal for retail stores, corporate lobbies, museums, exhibitions, and entertainment venues. The P1.86 Flexible LED Display combines innovative design, reliability, and exceptional visual performance.

Magnetic Installation: Quick, secure, tool-free mounting
Extreme Bending Radius: Seamless curvature to fit complex and creative surfaces
Ultra Thin Design: Sleek, lightweight, space-saving profile
Color Depth: Advanced 14-18 bit color depth for enhanced detail
High Color Uniformity: Consistent, vibrant, true-to-life colors across the display
It Comes with Complete Front Maintenance
Upgradable Module Design: Modular architecture extends performance
Super Wide View: Consistent image quality from ultra-wide viewing angles
Ultra High Refresh Rate: >=3840Hz for flicker-free, smooth motion
Reliability: Single-lamp maintenance and modular design for long-term service

Key Specifications

Headline specifications from the product Datasheet. Full model-by-model detail is in the PDF.

Item	PeopleLink Active LED 1.86 Flexible
Pixel pitch	1.86mm
Brightness	600-800 nits
Viewing angle	160 degrees

Rooms It Serves

Curved and Shaped Walls

Magnetic, bendable modules with a 500mm Bending Radius wrap columns, pillars and wave shaped surfaces.

Retail and Corporate Lobbies

Brightness of 600 to 800 nits with a GOB protected surface for busy branded spaces.

Theatrical and Stage Sets

Curved, seamless Direct View surfaces that can be reshaped between productions.

Where a LED Video Wall Fits in Your Organisation

How organisations deploy a LED Video Wall, and what changes for the teams that use it

Retail

Curved Experience Wall for a Retail Flagship

A flagship store builds a curved product wall with the Active LED 1.86 Flexible. The 500mm Bending Radius wraps a column at the store entrance, and the GOB-protected surface resists knocks from shoppers and trolleys. Campaign content runs at 600 to 800 nits across the 160-degree Viewing Angle, so it reads from the street and from inside the store.

Public Spaces

Cylindrical Information Column for an Airport Lounge

An airport lounge in the Middle East installs a cylindrical column for flight information and wayfinding. Magnetic, tool free mounting speeds the fit out in a live terminal, where contractors work in short overnight windows. Front Service Maintenance means later upkeep is done from the visible face, so the lounge stays open. The 160 by 160 degree Viewing Angle keeps departure times readable to passengers walking around the column rather than standing in front of it, and 600 to 800 nits holds up under terminal lighting.

Venues

Stage Set Element for a Theatre

A theatre uses the 1.86 Flexible as a bendable scenic element behind performers. Wave and curve shapes are re formed between productions without rigid cabinet frames, so one investment serves many set designs. The seamless GOB surface reads cleanly for recorded performances, and a 10000:1 Contrast Ratio holds shadow detail under stage lighting. The display pairs with PeopleLink Cameras and Audio for live streaming, so a production reaches an online audience from the same room design that serves the auditorium.

Not sure which model fits your Curved and Shaped Walls or Retail and Corporate Lobbies?

Tell us the room size and seating. A PeopleLink specialist will recommend the right model.

Talk to Sales

How It Compares

Capability	PeopleLink Active LED 1.86 Flexible	Typical Alternative
Form factor	Magnetic, bendable module, R500mm bending radius	Rigid flat cabinets only
LED protection	GOB (Glue on Board) protected surface	Exposed SMD lamps
Installation	Tool-free magnetic mounting	Bolted / screwed cabinets
Maintenance	Front service, upgradable modules	Whole-module swap

Why PeopleLink

Hardware and Software

Displays, Cameras, Audio and Collaboration Platforms, built by one OEM.

Integrates Cleanly

PeopleLink Displays pair with PeopleLink Cameras, Audio and Room Solutions out of the box.

Deployed Globally

Trusted across Enterprise, Government, Education and Healthcare environments.

Specialist Support

Talk to PeopleLink AV Specialists for sizing, integration and rollout.
